HT9811B Programmable DC Electronic Load 200W-500V-18A

The HT9811B programmable DC electronic load supports four standard operating modes: Constant Current (CC), Constant Resistance (CR), Constant Voltage (CV) and Constant Power (CP). It is also equipped with abundant advanced test functions including auto-test, dynamic test, over-current test and timing sequence test. Equipped with a brand-new large touchscreen, the instrument solves the pain points of complicated parameter setup and cumbersome operation of traditional loads. The collaborative design of touch screen, physical buttons and adjustment knob allows users to configure complex test procedures and parameters rapidly without frequent page switching, greatly improving test efficiency. The intuitive display interface effectively avoids parameter setting errors. Standard RS232 and RS485 communication interfaces are pre-installed for seamless integration into various automated test systems. An external IO trigger port is also reserved for connecting external trigger signals.

• Four operation modes: CC, CV, CR, CP
• Auto-test & list sequential test functions
• Dynamic mode up to 50kHz
• High measurement resolution: 0.1mV for voltage, 0.1mA for current
• Dedicated battery test function
• OCP test & remote sense measurement function
• Built-in short-circuit simulation function
• Special CR mode for LED testing
• Voltage & current ripple measurement capability
• Parameter memory retention after power-off
• Storage capacity for 100 groups of test records
• Standard RS232 & RS485 communication ports
